2014 Rose Xeon Team GF geometry
Full frame geometry for the 2014 Rose Xeon Team GF, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 51 | 534 | 373 | 75.3 | 71 | 135 | 514 | 450 | 582 | 408 | 980 |
| 53 | 552 | 379 | 75 | 71.5 | 153 | 526 | 475 | 589 | 408 | 987 |
| 55 | 566 | 383 | 74.5 | 72 | 168 | 540 | 495 | 594 | 408 | 992 |
| 57 | 583 | 388 | 74 | 72.5 | 185 | 555 | 515 | 599 | 408 | 997 |
All measurements in millimetres unless marked (°) for angles.
