2021 Pardus · RD
2021 Pardus Super Sport geometry
Full frame geometry for the 2021 Pardus Super Sport, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 45 | 499 | 371 | 75 | 71 | 105 | 505 | 68 | 405 | 967 | 45 |
| 50 | 520 | 381 | 74.5 | 72 | 125 | 525 | 68 | 405 | 974 | 45 |
| 52.5 | 542 | 385 | 73.5 | 72.5 | 145 | 545 | 68 | 405 | 980 | 45 |
| 54.5 | 563 | 388 | 73 | 73 | 165 | 560 | 68 | 408 | 989 | 45 |
| 56 | 567 | 402 | 73 | 73 | 170 | 575 | 68 | 408 | 1003 | 45 |
All measurements in millimetres unless marked (°) for angles.
