2015 Norco Search Steel geometry
Full frame geometry for the 2015 Norco Search Steel, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | 529 | 368 | 74.8 | 70.8 | 105 | 513 | 425 | 695 | 73 | 584 | 435 | 1008 |
| 50.5 | 545 | 371 | 74.3 | 71.3 | 120 | 525 | 450 | 715 | 73 | 588 | 435 | 1012 |
| 53 | 562 | 376 | 73.5 | 72 | 138 | 543 | 480 | 745 | 70 | 592 | 435 | 1017 |
| 55.5 | 585 | 384 | 73.3 | 72.3 | 160 | 560 | 510 | 775 | 70 | 604 | 435 | 1030 |
| 58 | 604 | 393 | 73 | 72.5 | 183 | 578 | 540 | 805 | 68 | 617 | 435 | 1043 |
| 60.5 | 627 | 400 | 72.8 | 72.8 | 205 | 595 | 570 | 830 | 68 | 629 | 435 | 1055 |
All measurements in millimetres unless marked (°) for angles.
