2019 Norco Revolver FS 100 geometry
Full frame geometry for the 2019 Norco Revolver FS 100, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 579 | 460 | 76 | 68.5 | 90 | 604 | 440 | 708 | 40 | 728 | 423 | 1148 | 51 | 92 |
| S | 579 | 430 | 76 | 68.5 | 90 | 574 | 425 | 700 | 40 | 698 | 420 | 1115 | 51 | 92 |
| L | 588 | 490 | 76 | 68.5 | 100 | 637 | 485 | 708 | 40 | 761 | 427 | 1185 | 51 | 92 |
| XL | 597 | 520 | 76 | 68.5 | 110 | 669 | 510 | 717 | 40 | 795 | 430 | 1222 | 51 | 92 |
All measurements in millimetres unless marked (°) for angles.
