2021 Norco Fluid H1 27.5 geometry
Full frame geometry for the 2021 Norco Fluid H1 27.5, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 585 | 380 | 74.5 | 66 | 100 | 542 | 370 | 598 | 40 | 430 | 1097 | 42 | 114 |
| S | 594 | 410 | 74.5 | 66 | 110 | 575 | 390 | 617 | 40 | 430 | 1131 | 42 | 114 |
| M | 603 | 440 | 74.5 | 66 | 120 | 607 | 420 | 647 | 40 | 430 | 1165 | 42 | 114 |
All measurements in millimetres unless marked (°) for angles.
