2025 Fezzari La Sal Peak geometry
Full frame geometry for the 2025 Fezzari La Sal Peak, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S (GA-High) | 606.9 | 450.7 | 73.6 | 64.2 | 90 | 568.1 | 400 | 739.6 | 18.9 | 437 | 1213 | 44 |
| S (GA-Low) | 612.6 | 435 | 72.9 | 63.5 | 90 | 568.1 | 400 | 739.6 | 26.4 | 437 | 1206.1 | 44 |
| M (GA-High) | 615.9 | 465.7 | 74.3 | 64.2 | 100 | 584.9 | 420 | 741.6 | 18.9 | 437 | 1233 | 44 |
| M (GA-Low) | 621.6 | 455 | 73.6 | 63.5 | 100 | 584.9 | 420 | 741.6 | 26.4 | 437 | 1230.4 | 44 |
| L (GA-High) | 625 | 491.9 | 74.8 | 64.2 | 110 | 613.1 | 440 | 742.6 | 18.9 | 437 | 1263 | 44 |
| L (GA-Low) | 630.6 | 485 | 74.1 | 63.5 | 110 | 613.1 | 440 | 742.6 | 26.4 | 437 | 1264.8 | 44 |
| XL (GA-High) | 634 | 514.3 | 75.1 | 64.2 | 120 | 637.2 | 460 | 744.6 | 18.9 | 437 | 1290 | 44 |
| XL (GA-Low) | 639.5 | 510 | 74.6 | 63.5 | 120 | 637.2 | 460 | 744.6 | 26.4 | 437 | 1294.2 | 44 |
All measurements in millimetres unless marked (°) for angles.
