2024 Fezzari Veyo geometry
Full frame geometry for the 2024 Fezzari Veyo, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 510 | 368 | 75 | 72 | 98 | 505 | 423 | 716 | 72 | 410 | 961 | 45 | 63 |
| S | 530 | 382 | 75 | 72.5 | 119 | 525 | 466 | 748 | 70 | 410 | 979 | 45 | 60 |
| M | 557 | 391 | 74.5 | 73 | 146 | 545 | 497 | 777 | 70 | 410 | 990 | 45 | 57 |
| L | 570 | 401 | 74 | 73 | 159 | 565 | 525 | 798 | 70 | 410 | 1005 | 45 | 57 |
| XL | 590 | 411 | 73.5 | 73.5 | 180 | 585 | 555 | 822 | 68 | 410 | 1016 | 45 | 54 |
All measurements in millimetres unless marked (°) for angles.
