2025 Fezzari Shafer 3.0 geometry
Full frame geometry for the 2025 Fezzari Shafer 3.0, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 550 | 368 | 71.6 | 69 | 84 | 525 | 420 | 730 | 78 | 425 | 1021 | 50 | 83 |
| S | 560 | 387 | 72.3 | 69 | 95 | 545 | 450 | 750 | 78 | 428 | 1046 | 50 | 83 |
| M | 585 | 400 | 72.8 | 69 | 121 | 565 | 480 | 770 | 78 | 431 | 1072 | 50 | 83 |
| L | 615 | 410 | 73.3 | 69 | 154 | 585 | 510 | 800 | 78 | 435 | 1098 | 50 | 83 |
| XL | 635 | 423 | 73.8 | 69 | 175 | 605 | 540 | 825 | 78 | 440 | 1124 | 50 | 83 |
All measurements in millimetres unless marked (°) for angles.
