2026 Yeti MTe geometry
Full frame geometry for the 2026 Yeti MTe, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SM | 615 | 430 | 77 | 64 | 93 | 572 | 390 | 722 | 764 | 449 | 1213 | 44 |
| MD | 625 | 460 | 77 | 64 | 104 | 604 | 420 | 742 | 799 | 449 | 1248 | 44 |
| LG | 635 | 480 | 77 | 64 | 115 | 627 | 440 | 742 | 824 | 449 | 1273 | 44 |
| XL | 645 | 505 | 77 | 64 | 126 | 654 | 460 | 742 | 854 | 449 | 1303 | 44 |
All measurements in millimetres unless marked (°) for angles.
