2018 Santa Cruz Tallboy Low Carbon geometry
Full frame geometry for the 2018 Santa Cruz Tallboy Low Carbon, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 594 | 405 | 73 | 68 | 90 | 574 | 390 | 705 | 40 | 684 | 432 | 1116 |
| L | 603 | 450 | 73 | 68 | 100 | 623 | 450 | 707 | 40 | 733 | 432 | 1165 |
| M | 603 | 430 | 73 | 68 | 100 | 603 | 420 | 706 | 40 | 713 | 432 | 1145 |
| XL | 617 | 475 | 73 | 68 | 115 | 653 | 480 | 709 | 40 | 763 | 432 | 1195 |
| XXL | 631 | 505 | 73 | 68 | 130 | 689 | 510 | 704 | 40 | 799 | 432 | 1231 |
All measurements in millimetres unless marked (°) for angles.
