2027 Santa Cruz Bullit geometry
Full frame geometry for the 2027 Santa Cruz Bullit, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 622 | 435 | 78.6 | 63.6 | 100 | 571 | 380 | 745 | 27 | 780 | 440 | 1220 | 44 |
| M | 631 | 460 | 78.7 | 63.6 | 110 | 596 | 400 | 739 | 27 | 809 | 443 | 1252 | 44 |
| L | 640 | 480 | 78.7 | 63.6 | 120 | 617 | 420 | 738 | 27 | 834 | 446 | 1280 | 44 |
| XL | 654 | 500 | 78.7 | 63.6 | 135 | 640 | 460 | 738 | 27 | 860 | 449 | 1309 | 44 |
| XXL | 670 | 525 | 78.6 | 63.6 | 155 | 670 | 500 | 735 | 27 | 894 | 452 | 1346 | 44 |
All measurements in millimetres unless marked (°) for angles.
