2025 Quick GR One geometry
Full frame geometry for the 2025 Quick GR One, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 524 | 370 | 74.2 | 70.5 | 95 | 518 | 426 | 723 | 75 | 425 | 55 |
| S | 543 | 379 | 74 | 71 | 113 | 535 | 456 | 742 | 75 | 425 | 55 |
| M | 561 | 388 | 73.6 | 71 | 132 | 553 | 486 | 760 | 75 | 425 | 55 |
| L | 580 | 398 | 73.3 | 71 | 152 | 572 | 516 | 779 | 75 | 425 | 55 |
| XL | 599 | 405 | 73.8 | 71 | 172 | 590 | 546 | 798 | 75 | 425 | 55 |
All measurements in millimetres unless marked (°) for angles.
