2022 No22 Great Divide geometry
Full frame geometry for the 2022 No22 Great Divide, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 48cm | 506 | 357 | 75 | 70.5 | 90 | 495 | 730 | 78 | 567 | 412 |
| 50cm | 517 | 364 | 74.5 | 71 | 100 | 510 | 743 | 78 | 574 | 412 |
| 52cm | 534 | 370 | 74 | 71.2 | 120 | 525 | 767 | 75 | 584 | 412 |
| 54cm | 558 | 379 | 73.5 | 72.2 | 140 | 545 | 793 | 75 | 586 | 415 |
| 56cm | 578 | 383 | 73 | 72.5 | 160 | 560 | 813 | 75 | 594 | 415 |
| 58cm | 597 | 397 | 73 | 73 | 180 | 580 | 836 | 73 | 609 | 415 |
| 60cm | 617 | 406 | 72.5 | 73 | 200 | 600 | 858 | 73 | 623 | 418 |
All measurements in millimetres unless marked (°) for angles.
