2017 Juliana Strega geometry
Full frame geometry for the 2017 Juliana Strega, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS-High | 584 | 390 | 74.5 | 65 | 90 | 540 | 375 | 710 | 10 | 704 | 430 | 1134 |
| XS-Low | 587 | 386 | 74.1 | 64.6 | 90 | 541 | 375 | 704 | 15 | 704 | 431 | 1135 |
| S-High | 593 | 420 | 74.5 | 65 | 100 | 573 | 390 | 712 | 10 | 738 | 430 | 1168 |
| S-Low | 596 | 416 | 74.1 | 64.6 | 100 | 574 | 390 | 706 | 15 | 738 | 431 | 1169 |
| M-High | 602 | 440 | 74.5 | 65 | 110 | 596 | 420 | 728 | 10 | 762 | 430 | 1192 |
| M-Low | 605 | 436 | 74.1 | 64.6 | 110 | 598 | 420 | 722 | 15 | 762 | 431 | 1194 |
All measurements in millimetres unless marked (°) for angles.
