2019 Juliana Quincy geometry
Full frame geometry for the 2019 Juliana Quincy, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 530 | 365 | 74.5 | 69.5 | 110 | 512 | 470 | 730 | 74 | 594 | 425 | 1006 |
| 52 | 555 | 372 | 74.5 | 71 | 130 | 526 | 495 | 754 | 74 | 595 | 425 | 1009 |
| 54 | 576 | 380 | 74 | 71.5 | 150 | 545 | 520 | 776 | 72 | 600 | 425 | 1015 |
All measurements in millimetres unless marked (°) for angles.
