2019 Ghost Road Rage geometry
Full frame geometry for the 2019 Ghost Road Rage, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 527 | 359 | 74.5 | 70 | 120 | 505 | 445 | 746 | 55 | 588 | 430 | 1012 |
| S | 544 | 371 | 74 | 70.5 | 135 | 525 | 465 | 776 | 55 | 601 | 432 | 1027 |
| M | 554 | 381 | 73.5 | 71 | 150 | 545 | 482 | 794 | 52 | 610 | 432 | 1037 |
| L | 573 | 393 | 73 | 71.5 | 165 | 568 | 505 | 814 | 52 | 623 | 432 | 1050 |
| XL | 589 | 404 | 72.5 | 72 | 180 | 690 | 530 | 824 | 52 | 635 | 432 | 1062 |
All measurements in millimetres unless marked (°) for angles.
