2016 Fuji Rakan 29 geometry
Full frame geometry for the 2016 Fuji Rakan 29, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M/17 | 610 | 421 | 74.5 | 69 | 105 | 590 | 432 | 861 | 32 | 776 | 450 | 1146 | 51 |
| S/15 | 610 | 386 | 74.5 | 69 | 105 | 555 | 381 | 835 | 32 | 766 | 450 | 1111 | 51 |
| L/19 | 620 | 440 | 74.5 | 69 | 115 | 612 | 483 | 893 | 32 | 775 | 450 | 1169 | 51 |
| XL/21 | 620 | 469 | 74.5 | 69 | 115 | 641 | 533 | 919 | 32 | 793 | 450 | 1198 | 51 |
All measurements in millimetres unless marked (°) for angles.
