2012 Fuji Altamira geometry
Full frame geometry for the 2012 Fuji Altamira, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 517 | 363 | 75 | 72 | 120 | 515 | 440 | 722 | 69 | 576 | 405 | 971 | 45 | 61 |
| SM | 528 | 370 | 74.5 | 72.5 | 130 | 530 | 470 | 741 | 69 | 582 | 405 | 977 | 45 | 58 |
| M | 540 | 370 | 73.5 | 73 | 140 | 545 | 500 | 760 | 69 | 581 | 405 | 976 | 45 | 55 |
| ML | 560 | 379 | 73.5 | 73.5 | 160 | 560 | 530 | 783 | 69 | 591 | 405 | 986 | 45 | 52 |
| L | 580 | 389 | 73.5 | 73.5 | 180 | 575 | 550 | 801 | 69 | 605 | 405 | 1001 | 45 | 52 |
| L/XL | 601 | 397 | 73.5 | 74 | 200 | 590 | 580 | 821 | 69 | 615 | 405 | 1010 | 45 | 49 |
All measurements in millimetres unless marked (°) for angles.
