2018 Commencal Meta HT Trail geometry
Full frame geometry for the 2018 Commencal Meta HT Trail, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 584 | 367 | 73 | 68.5 | 100 | 545 | 350 | 680 | 50 | 435 | 1040 |
| S | 593 | 384 | 73 | 68.5 | 110 | 565 | 400 | 700 | 50 | 435 | 1060 |
| M | 612 | 398 | 73 | 68 | 110 | 585 | 450 | 725 | 48 | 435 | 1080 |
| L | 621 | 420 | 73 | 68 | 120 | 610 | 500 | 755 | 48 | 435 | 1105 |
| XL | 630 | 442 | 73 | 68 | 130 | 635 | 530 | 785 | 48 | 435 | 1130 |
All measurements in millimetres unless marked (°) for angles.
