2017 Commencal Absolut geometry
Full frame geometry for the 2017 Commencal Absolut, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| L/XL | 578 | 426 | 73 | 69 | 120 | 600 | 345 | 720 | 30 | 390 | 1069 |
| SM | 578 | 386 | 73 | 69 | 120 | 570 | 345 | 715 | 25 | 390 | 1027 |
All measurements in millimetres unless marked (°) for angles.
