2018 Whyte 529/629 geometry
Full frame geometry for the 2018 Whyte 529/629, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| S | 642 | 431 | 75.5 | 66.5 | 110 | 609 | 406 | 810 | 425 | 1146 |
| M | 646 | 449 | 76.5 | 66.5 | 115 | 628 | 444 | 820 | 425 | 1166 |
| L | 651 | 467 | 77.5 | 66.5 | 120 | 648 | 496 | 846 | 425 | 1186 |
| XL | 664 | 481 | 78.5 | 66.5 | 135 | 665 | 533 | 860 | 425 | 1206 |
All measurements in millimetres unless marked (°) for angles.
