2018 Sensa Trentino SL geometry
Full frame geometry for the 2018 Sensa Trentino SL, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 51 | 528 | 376 | 73.5 | 72 | 130 | 532 | 505 | 788 | 68 | 978 | 45 |
| 54 | 551 | 380 | 73.5 | 73 | 150 | 543 | 535 | 815 | 68 | 980 | 45 |
| 56 | 570 | 385 | 73.5 | 73 | 170 | 553 | 555 | 835 | 68 | 991 | 45 |
| 58 | 589 | 390 | 73 | 73 | 190 | 570 | 575 | 855 | 68 | 1002 | 45 |
| 60 | 608 | 394 | 73 | 73 | 210 | 580 | 595 | 875 | 68 | 1012 | 45 |
| 62 | 619 | 406 | 73 | 73.5 | 220 | 595 | 615 | 891 | 68 | 1022 | 45 |
All measurements in millimetres unless marked (°) for angles.
