2018 Sensa Trentino Endura geometry
Full frame geometry for the 2018 Sensa Trentino Endura, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 51 | 535 | 371 | 74.5 | 72 | 130 | 519 | 510 | 792 | 68 | 979 | 46 |
| 54 | 561 | 375 | 74 | 72.5 | 155 | 536 | 540 | 822 | 68 | 987 | 46 |
| 56 | 580 | 379 | 73.5 | 72.5 | 175 | 551 | 560 | 842 | 68 | 997 | 46 |
| 58 | 604 | 383 | 73 | 72.5 | 200 | 568 | 580 | 865 | 68 | 1009 | 46 |
| 61 | 624 | 387 | 72.5 | 73 | 220 | 584 | 610 | 892 | 68 | 1013 | 46 |
All measurements in millimetres unless marked (°) for angles.
