2015 Ritchey Swiss Cross Disc MK I geometry
Full frame geometry for the 2015 Ritchey Swiss Cross Disc MK I, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 528 | 368 | 74.5 | 71 | 100 | 515 | 460 | 756 | 63 | 576 | 425 | 993 | 45 | 73 |
| 51 | 544 | 371 | 74 | 71.5 | 115 | 527 | 475 | 771 | 63 | 579 | 425 | 996 | 45 | 70 |
| 53 | 558 | 380 | 74 | 71.5 | 130 | 540 | 495 | 787 | 63 | 593 | 425 | 1010 | 45 | 70 |
| 55 | 579 | 383 | 73.5 | 72 | 150 | 555 | 515 | 807 | 63 | 598 | 425 | 1015 | 45 | 66 |
| 57 | 598 | 391 | 73.5 | 72 | 170 | 568 | 535 | 826 | 63 | 612 | 425 | 1029 | 45 | 66 |
| 59 | 617 | 391 | 73 | 72 | 190 | 580 | 555 | 845 | 63 | 618 | 425 | 1035 | 45 | 66 |
All measurements in millimetres unless marked (°) for angles.
