2016 Lynskey TSL 3.1 geometry
Full frame geometry for the 2016 Lynskey TSL 3.1, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 502 | 401 | 78 | 71 | 100 | 510 | 515 | 757 | 67 | 601 | 394 | — | 43 |
| M | 515 | 412 | 78 | 72 | 110 | 525 | 532 | 770 | 67 | 607 | 394 | 991 | 43 |
| ML | 539 | 427 | 78 | 72 | 135 | 545 | 557 | 795 | 67 | 629 | 394 | — | 43 |
| L | 563 | 453 | 78 | 72 | 160 | 575 | 580 | 818 | 67 | 662 | 394 | 1047 | 43 |
| XL | 579 | 464 | 78 | 72.5 | 175 | 590 | 597 | 838 | 67 | 674 | 390 | 1055 | 43 |
All measurements in millimetres unless marked (°) for angles.
