2019 Kona Satori geometry
Full frame geometry for the 2019 Kona Satori, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 609 | 425 | 78.4 | 68 | 95 | 550 | 370 | 726 | 29 | 715 | 430 | 1143 | 51 |
| M | 618 | 450 | 78.4 | 68 | 105 | 577 | 420 | 763 | 29 | 744 | 430 | 1172 | 51 |
| L | 627 | 475 | 78.3 | 68 | 115 | 605 | 470 | 763 | 29 | 772 | 430 | 1201 | 51 |
| XL | 637 | 510 | 78.3 | 68 | 125 | 642 | 530 | 783 | 29 | 811 | 430 | 1240 | 51 |
All measurements in millimetres unless marked (°) for angles.
