2016 Kona Process 167 geometry
Full frame geometry for the 2016 Kona Process 167, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 586 | 424 | 75 | 65 | 105 | 582 | 387 | 640 | 2 | 741 | 420 | 1160 | 40 |
| M | 595 | 450 | 75 | 65 | 115 | 611 | 387 | 640 | 2 | 771 | 420 | 1191 | 40 |
| L | 600 | 475 | 75 | 65 | 120 | 638 | 432 | 640 | 2 | 798 | 420 | 1218 | 40 |
All measurements in millimetres unless marked (°) for angles.
