2019 Kona Honzo Al MK II geometry
Full frame geometry for the 2019 Kona Honzo Al MK II, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 624 | 425 | 75 | 68 | 90 | 592 | 370 | 730 | 65 | 709 | 415 | 1116 | 51 |
| M | 633 | 450 | 75 | 68 | 100 | 620 | 420 | 730 | 65 | 737 | 415 | 1144 | 51 |
| L | 642 | 475 | 75 | 68 | 110 | 647 | 470 | 740 | 65 | 766 | 415 | 1173 | 51 |
| XL | 651 | 510 | 75 | 68 | 120 | 685 | 530 | 760 | 65 | 805 | 415 | 1212 | 51 |
All measurements in millimetres unless marked (°) for angles.
