2017 Jamis Dragon Slayer 26 geometry
Full frame geometry for the 2017 Jamis Dragon Slayer 26, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 591 | 394 | 73 | 68 | 90 | 575 | 756 | 39 | 425 | 1089 |
| 17 | 600 | 411 | 73 | 68 | 100 | 595 | 793 | 39 | 425 | 1107 |
| 19 | 619 | 426 | 73 | 68 | 120 | 615 | 830 | 39 | 425 | 1128 |
| 21 | 637 | 446 | 73 | 68 | 140 | 635 | 866 | 39 | 425 | 1157 |
All measurements in millimetres unless marked (°) for angles.
