2018 BH Rebel Volt Lite geometry
Full frame geometry for the 2018 BH Rebel Volt Lite, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Front centre (mm) | Chainstay (mm) |
|---|---|---|---|---|---|---|---|---|---|
| M | 302 | 462 | 71 | 70 | 100 | 569 | 315 | 630 | 370 |
All measurements in millimetres unless marked (°) for angles.
