2025 Van Rysel XCR Tri geometry
Full frame geometry for the 2025 Van Rysel XCR Tri, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 469 | 380 | 79 | 71 | 65 | 489 | 485 | 74.6 | 422 | 979 | 45 |
| S | 480 | 402 | 79 | 72 | 74 | 513 | 495 | 74.6 | 422 | 996 | 45 |
| M | 498 | 419 | 79 | 72 | 92 | 534 | 516 | 74.6 | 422 | 1019 | 45 |
| L | 519 | 436 | 79 | 72 | 115 | 556 | 530 | 74.6 | 422 | 1043 | 45 |
| XL | 539 | 444 | 80 | 72 | 136 | 571 | 550 | 74.6 | 422 | 1058 | 45 |
All measurements in millimetres unless marked (°) for angles.
