2017 Silverback Square geometry
Full frame geometry for the 2017 Silverback Square, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| L | 604 | 452 | 74 | 69 | 110 | 625 | 500 | 800 | 445 | 1169 |
| M | 604 | 426 | 74 | 69 | 110 | 600 | 450 | 780 | 445 | 1144 |
| S | 604 | 396 | 74 | 69 | 110 | 570 | 400 | 774 | 445 | 1114 |
| XL | 614 | 461 | 74 | 69 | 120 | 637 | 550 | 827 | 445 | 1182 |
All measurements in millimetres unless marked (°) for angles.
