2016 SE Bikes Big Mountain 27.5 geometry
Full frame geometry for the 2016 SE Bikes Big Mountain 27.5, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M/17 | 607 | 400 | 73.5 | 70 | 130 | 580 | 432 | 814 | 45 | 651 | 430 | 1077 | 42 |
| S/15 | 607 | 385 | 73.5 | 70 | 115 | 565 | 381 | 778 | 45 | 636 | 430 | 1062 | 42 |
| L/19 | 621 | 416 | 73.5 | 70 | 130 | 600 | 483 | 832 | 45 | 672 | 430 | 1098 | 42 |
| XL/21 | 630 | 433 | 73.5 | 70 | 140 | 620 | 533 | 861 | 45 | 693 | 430 | 1119 | 42 |
All measurements in millimetres unless marked (°) for angles.
