2014 Scott Plasma 5 geometry
Full frame geometry for the 2014 Scott Plasma 5, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S/51 | 510 | 380 | 74 | 72 | 110 | 524 | 530 | 779 | 65 | 571 | 403 | 965 |
| M/54 | 540 | 397 | 75 | 73 | 138 | 544 | 560 | 809 | 65 | 589 | 403 | 983 |
| L/57 | 570 | 414 | 75 | 73 | 170 | 564 | 589 | 839 | 65 | 615 | 403 | 1009 |
| XL/60 | 600 | 430 | 76 | 73.5 | 199 | 583 | 619 | 869 | 65 | 635 | 403 | 1029 |
All measurements in millimetres unless marked (°) for angles.
