2015 Scott Genius MK I geometry
Full frame geometry for the 2015 Scott Genius MK I, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S-High | 586 | 399 | 74.4 | 69.4 | 100 | 569 | 415 | 773 | 29 | 664 | 449 | 1112 |
| S-Low | 589 | 394 | 73.9 | 68.9 | 100 | 570 | 415 | 770 | 35 | 664 | 450 | 1112 |
| M-High | 595 | 429 | 74.4 | 69.4 | 100 | 599 | 440 | 776 | 29 | 694 | 449 | 1142 |
| M-Low | 598 | 424 | 73.9 | 68.9 | 100 | 600 | 440 | 773 | 35 | 694 | 450 | 1142 |
| L-High | 604 | 452 | 74.4 | 69.4 | 110 | 624 | 475 | 806 | 29 | 720 | 449 | 1168 |
| L-Low | 607 | 447 | 74 | 69 | 110 | 625 | 475 | 803 | 34 | 720 | 450 | 1168 |
| XL-High | 618 | 474 | 74.4 | 69.4 | 120 | 649 | 510 | 804 | 28 | 746 | 449 | 1194 |
| XL-Low | 621 | 469 | 74 | 69 | 120 | 650 | 510 | 801 | 34 | 746 | 450 | 1194 |
All measurements in millimetres unless marked (°) for angles.
