2018 Salsa Woodsmoke 29 geometry
Full frame geometry for the 2018 Salsa Woodsmoke 29, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| XS | 596 | 392 | 73.3 | 67.8 | 100 | 571 | 356 | 714 | 62 | 51 |
| S | 606 | 409 | 73.3 | 67.8 | 100 | 591 | 381 | 734 | 62 | 51 |
| M | 615 | 426 | 73.3 | 67.8 | 110 | 611 | 432 | 773 | 62 | 51 |
| L | 624 | 453 | 73.3 | 67.8 | 120 | 641 | 483 | 802 | 62 | 51 |
| XL | 633 | 481 | 73.3 | 67.8 | 130 | 671 | 533 | 831 | 62 | 51 |
All measurements in millimetres unless marked (°) for angles.
