2019 Salsa Spearfish MK II geometry
Full frame geometry for the 2019 Salsa Spearfish MK II, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 608 | 423 | 74.6 | 67.8 | 103 | 590 | 406 | 743 | 39 | 432 | 1140 | 51 |
| M | 617 | 442 | 74.4 | 67.8 | 113 | 614 | 444 | 742 | 39 | 432 | 1163 | 51 |
| L | 626 | 461 | 74.2 | 67.8 | 123 | 637 | 483 | 741 | 39 | 432 | 1186 | 51 |
| XL | 635 | 480 | 74.1 | 67.8 | 133 | 661 | 520 | 741 | 39 | 432 | 1209 | 51 |
All measurements in millimetres unless marked (°) for angles.
