2017 Giant XTC Advanced 29 MKII geometry
Full frame geometry for the 2017 Giant XTC Advanced 29 MKII, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 612 | 412 | 72.5 | 70 | 95 | 605 | 440 | 765 | 60 | 670 | 425 | 1088 | 51 | 82 |
| S | 612 | 398 | 73 | 70 | 95 | 585 | 390 | 739 | 60 | 656 | 425 | 1074 | 51 | 82 |
| L | 621 | 423 | 72 | 70 | 105 | 625 | 490 | 797 | 60 | 684 | 425 | 1102 | 51 | 82 |
| XL | 631 | 440 | 72 | 70 | 115 | 645 | 535 | 827 | 60 | 704 | 425 | 1122 | 51 | 82 |
All measurements in millimetres unless marked (°) for angles.
