2017 Giant Trance Advanced MKII geometry
Full frame geometry for the 2017 Giant Trance Advanced MKII, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 587 | 406 | 73.5 | 67 | 100 | 580 | 380 | 701 | 15 | 694 | 435 | 1129 | 42 | 104 |
| XS | 587 | 386 | 73.5 | 67 | 100 | 560 | 370 | 697 | 15 | 674 | 435 | 1109 | 42 | 104 |
| M | 591 | 435 | 73.5 | 67 | 105 | 610 | 431 | 723 | 15 | 725 | 435 | 1160 | 42 | 104 |
| L | 614 | 448 | 73.5 | 67 | 130 | 630 | 482 | 768 | 15 | 748 | 435 | 1183 | 42 | 104 |
| XL | 628 | 469 | 73.5 | 67 | 145 | 655 | 507 | 788 | 15 | 774 | 435 | 1209 | 42 | 104 |
All measurements in millimetres unless marked (°) for angles.
