2027 Giant Talon 1 geometry
Full frame geometry for the 2027 Giant Talon 1, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 606 | 435 | 74.5 | 67.5 | 105 | 604 | 420 | 708 | 55 | 455 | 1164 | 44 | 109 |
| L | 625 | 455 | 74.5 | 67.5 | 125 | 629 | 450 | 708 | 55 | 455 | 1191 | 44 | 109 |
| XL | 638 | 475 | 74.5 | 67.5 | 140 | 653 | 480 | 710 | 55 | 455 | 1216 | 44 | 109 |
All measurements in millimetres unless marked (°) for angles.
