2024 Giant SCR 2 geometry
Full frame geometry for the 2024 Giant SCR 2, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 524 | 372 | 74.8 | 71 | 123 | 515 | 410 | 720 | 75 | 412 | 985 | 50 | 68.2 |
| S | 541 | 375 | 74 | 71.8 | 138 | 530 | 445 | 746 | 75 | 412 | 986 | 50 | 63.3 |
| M | 563 | 378 | 73.5 | 72.5 | 158 | 545 | 480 | 774 | 75 | 412 | 990 | 50 | 58.4 |
All measurements in millimetres unless marked (°) for angles.
