2015 Cannondale Tango 29 geometry
Full frame geometry for the 2015 Cannondale Tango 29, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 596 | 373 | 73.5 | 70.5 | 90 | 550 | 381 | 767 | 65 | 613 | 444 | 1048 | 45 | 83 |
| M | 610 | 389 | 73.5 | 71 | 102 | 570 | 419 | 794 | 65 | 628 | 444 | 1064 | 45 | 80 |
| TL | 622 | 400 | 73 | 71 | 114 | 590 | 457 | 817 | 65 | 643 | 444 | 1078 | 45 | 80 |
All measurements in millimetres unless marked (°) for angles.
