2026 Cannondale SuperSlice geometry
Full frame geometry for the 2026 Cannondale SuperSlice, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 461 | 388 | 71.5 | 50 | 478 | 440 | 388 | 73 | 575 | 415 | 979 | 50 | 62 |
| SM | 487 | 402 | 71.5 | 77 | 497 | 490 | 402 | 73 | 598 | 415 | 1002 | 50 | 62 |
| MD | 514 | 417 | 71.5 | 106 | 517 | 551 | 417 | 73 | 622 | 415 | 1026 | 50 | 62 |
| LG | 540 | 431 | 71.5 | 133 | 536 | 585 | 431 | 73 | 644 | 415 | 1048 | 50 | 62 |
All measurements in millimetres unless marked (°) for angles.
