2015 Cannondale Jekyll geometry
Full frame geometry for the 2015 Cannondale Jekyll, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 590 | 426 | 75 | 65 | 102 | 584 | 400 | 750 | 8 | 746 | 420 | 1166 | 44 | 108 |
| M | 601 | 448 | 75 | 65 | 115 | 609 | 430 | 758 | 8 | 773 | 420 | 1193 | 44 | 108 |
| L | 612 | 470 | 75 | 65 | 127 | 634 | 460 | 767 | 8 | 800 | 420 | 1220 | 44 | 108 |
| XL | 624 | 495 | 75 | 65 | 140 | 662 | 520 | 775 | 8 | 831 | 420 | 1250 | 44 | 108 |
All measurements in millimetres unless marked (°) for angles.
