2021 Cannondale Adventure Neo geometry
Full frame geometry for the 2021 Cannondale Adventure Neo, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SM | 688 | 370 | 72 | 70 | 215 | 484 | 370 | 445 | 68 | 644 | 488 | 1124 | 42 | 83 |
| LG | 707 | 406 | 72 | 70 | 235 | 518 | 406 | 455 | 68 | 686 | 488 | 1166 | 42 | 83 |
All measurements in millimetres unless marked (°) for angles.
