2025 YT Szepter CF geometry
Full frame geometry for the 2025 YT Szepter CF, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 568 | 384 | 74.3 | 69.3 | 125 | 558 | 450 | 740 | 61 | 425 | 1054 |
| M | 587 | 398 | 74.4 | 69.4 | 145 | 578 | 480 | 764 | 61 | 425 | 1076 |
| L | 611 | 407 | 74.4 | 69.4 | 170 | 593 | 500 | 779 | 62 | 425 | 1095 |
| XL | 630 | 422 | 74.4 | 69.4 | 190 | 613 | 530 | 796 | 62 | 425 | 1115 |
| XXL | 644 | 433 | 74.4 | 69.4 | 205 | 628 | 550 | 809 | 62 | 425 | 1132 |
All measurements in millimetres unless marked (°) for angles.
