2012 Scapin Etika geometry
Full frame geometry for the 2012 Scapin Etika, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 529 | 382 | 74.5 | 72 | 130 | 528 | 480 | 770 | 70 | 582 | 404 | 976 | 45 |
| M | 546 | 391 | 74 | 72.5 | 147 | 547 | 500 | 789 | 70 | 592 | 406 | 988 | 45 |
| L | 567 | 397 | 73 | 73 | 165 | 567 | 520 | 812 | 70 | 597 | 409 | 996 | 45 |
| XL | 585 | 401 | 73 | 73 | 186 | 580 | 540 | 831 | 70 | 610 | 409 | 1009 | 45 |
All measurements in millimetres unless marked (°) for angles.
