2014 Pinarello Maat 60.1 geometry
Full frame geometry for the 2014 Pinarello Maat 60.1, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 42.5 | 472 | 398 | 76 | 73.5 | 80 | 518 | 455 | 46 | 545 | 369 | 909 | 19 | 79 |
| 45 | 488 | 409 | 76 | 74 | 95 | 533 | 480 | 46 | 558 | 369 | 922 | 19 | 76 |
| 47 | 502 | 418 | 75 | 74 | 110 | 553 | 500 | 46 | 570 | 369 | 934 | 19 | 76 |
| 48.5 | 517 | 434 | 75 | 74 | 125 | 573 | 515 | 46 | 590 | 369 | 954 | 19 | 76 |
| 50 | 531 | 450 | 75 | 74 | 140 | 593 | 530 | 46 | 610 | 369 | 974 | 19 | 76 |
All measurements in millimetres unless marked (°) for angles.
