2019 Pinarello Andromeda geometry
Full frame geometry for the 2019 Pinarello Andromeda, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 630 | 384 | 73.5 | 69 | 125 | 570 | 381 | 51 | 653 | 455 | 51 |
| S | 636 | 402 | 73.5 | 69 | 132 | 590 | 432 | 51 | 673 | 455 | 51 |
| M | 637 | 426 | 73.5 | 69 | 132 | 615 | 483 | 51 | 698 | 455 | 51 |
| L | 644 | 438 | 73 | 69 | 140 | 635 | 535 | 51 | 712 | 455 | 51 |
All measurements in millimetres unless marked (°) for angles.
