2022 Nicolai Argon GTB geometry
Full frame geometry for the 2022 Nicolai Argon GTB, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) |
|---|---|---|---|---|---|---|
| small | 623 | 435 | 110 | 608 | 405 | 689 |
| large | 635 | 474 | 120 | 650 | 490 | 775 |
| medium | 635 | 455 | 120 | 630 | 460 | 750 |
| x-large | 644 | 495 | 130 | 673 | 515 | 798 |
| xx-large | 660 | 516 | 150 | 700 | 545 | 825 |
All measurements in millimetres unless marked (°) for angles.
